Norden Vehicle Dash Camera with 2MP Resolution, ADAS, DSM, 4G, GPS, Wi-Fi and 10 m IR (Upgradable to 15 m) Support
Norden Vehicle Dash Camera with 2MP Resolution, ADAS, DSM, 4G, GPS, Wi-Fi and 10 m IR (Upgradable to 15 m) Support
MODEL | Model No. | ENC-HCD5F-10R-16 |
Type | 2MP VEHICLE DASH CAMERA | |
CAMERA | Day/Night | IR Cut Filter with Auto Switch |
| Lens Type | Fixed | |
| Focal Length | ADAS: 3.0 mm, DSM: 2.8 mm | |
Angle of View (H) | 3.0 mm: 125°, 2.8 mm: 118° | |
Angle of View (V) | 3.0 mm: 73°, 2.8 mm: 62° | |
| Angle of View (D) | 3.0 mm: 145°, 2.8 mm: 145° | |
| LDC | < 10% | |
| Aperture | F2.0 | |
| Smart IR | Up to 10 m (Upgradable to 15 m) | |
VIDEO | Max Resolution | ADAS: 1920x1080 DSM: 1280x720 External Cameras (2xAHD Camera): 1280x720 |
Video Compression | H.265, H.264 | |
| Frame Rate | ADAS: Main Stream: (1920x1080, 1280x720, 704x576, 720x480, 352x288) @ 25/30 fps Sub Stream: (704x576, 720x480, 352x288) @ 25/30 fps DSM: Main Stream: (1280x720, 704x576, 720x480, 352x288)@ 25/30 fps Sub Stream: (704x576, 720x480, 352x288) @ 25/30 fps External Cameras (2xAHD Camera): Main Stream: (1280x720, 704x576, 720x480, 352x288)@ 25/30 fps Sub Stream: (704x576, 720x480, 352x288) @ 25/30 fps | |
| Video Bit Rate | 256 kbps ~ 8 Mbps | |
| HLC | Supported | |
| BLC | Supported | |
| OSD | Supported | |
AUDIO | Audio Compression | G.711A |
| Built-in Mic | Supported | |
SMART | Driving Status Monitoring (DSM) | Head Down, Calling, Smoking, Looking Around, Yawning, Fatigue Driving (eyes closed), Face Obstruction, Masking |
Advanced Driving Assistance System (ADAS) | Lane Deviation, Pedestrian, Unsafe Distance | |
| Face Recognition | Supported | |
INTERFACE | Serial Interface | 1xRS232 |
| External Camera Interface | 2xAHD Camera | |
| G-Sensor | Supported | |
SIM | 1xMicro SIM Slot | |
Storage | 1xSD Card Slot, up to 512GB | |
| GPS | Supported | |
| Wi-Fi | Supported | |
| Frequency Bands | Wi-Fi: 802.11 b/g/n | |
| Built-in Speaker | Supported | |
GENERAL | Operating System | Linux |
Power Supply | 10 ~ 36V DC | |
| Max. Power Consumption | ≤5 W | |
| Working Temperature | -20°C ~ 70°C | |
| Working Humidity | 20% ~ 80% | |
| Color | Black | |
| SOS Button | Supported | |
| Ingress Protection | IP65 | |
| Reset Button | Supported | |
| Dimensions | 120x77x55 mm | |
| Weight | 0.26kg |
| Part Number | Description | Standard Quantity |
| ENC-HDC5F-10R-16 | Norden Vehicle Dash Camera with 2MP Resolution, ADAS, DSM, 4G, GPS, Wi-Fi and 10 m IR (Upgradable to 15 m) Support | 1 |
