The NFA-T01CD carbon monoxide detector is equipped with a high-sensitivity, long-life sensor and features automatic sensor life monitoring. Advanced high- and low-temperature compensation algorithms help minimize false alarms. Designed for ceiling-mounted installation, it ensures easy and efficient setup.
The NFA-T01CD carbon monoxide detector is equipped with a high-sensitivity, long-life sensor and features automatic sensor life monitoring. Advanced high- and low-temperature compensation algorithms help minimize false alarms. Designed for ceiling-mounted installation, it ensures easy and efficient setup.
Characteristics | Value | |
| Input Voltage | 24V DC (15V～28V pulse voltage) | |
| Current Consumption | Stand by 1.5mA, Alarm:15mA | |
| Output Mode | Active output, output current < 5mA | |
| Target Gas | Carbon monoxide (CO) | |
| Measurement/Sensor Range | 0~240 × 10⁻⁶ ppm | |
| Alarm Set Value | 150 × 10⁻⁶ ppm | |
| Sensor Lifetime | 5 Years | |
| LED Indicator | Normal Monitoring State: The green light flashes and the buzzer does not sound; Alarm State: The red light remains constantly illuminated and the buzzer sounds; Fault State: The yellow light remains constantly illuminated and the buzzer sounds intermittently; Sensor Service Life Expiry: The yellow light flashes and the buzzer sounds intermittently. | |
| Operating Temperature | -10°C～+55°C | |
| Humidity | 0 to 95% Relative Humidity, Non condensing | |
| Color | Beige | |
| Weight | 96g | |
| Dimension/Height | Diameter 100mm/49mm | |
Part Number | Description | |
| NFA-T01CD | ADDRESSABLE CO DETECTOR | |
