IR Strobe Illuminator with 40 Pieces High Power IR LED, 10° Beam Angle, 40m IR and IP66 Support
IR Strobe Illuminator with 40 Pieces High Power IR LED, 10° Beam Angle, 40m IR and IP66 Support
MODEL | Model No. | ENI-ISA010-040R |
Type | INTELLIGENT TRAFFIC STROBE LAMP | |
GENERAL | Beam Angle | 10° |
| Beam Distance | 40 m
| |
Best Distance for LPR | 20 ~ 40 m | |
Flash Trigger Method | Self Adaptation | |
| Synchronization Port | One Port Strobe Trigger Input
| |
| Response Time | ≤20μs | |
| Design Lifetime | ≥50000 Hrs | |
| Color | White
| |
| LED | 40 pcs LED | |
| Wavelength | 850 nm | |
| Power Supply | 110 ~ 220V AC | |
| Power Consumption | ≤32W | |
| Working Temperature | -40 °C ~ 70 °C | |
| Working Humidity | ≤90% | |
| Ingress Protection | IP66 | |
| Surge Protection | Common mode: 6KV, Differential mode: 3KV | |
| Material | Aluminium Die-Casting Housing | |
| Panel | Tempered glass | |
| Dimensions | 216x200x62 mm | |
| Net Weight | 2.8 kg | |
INSTALLATION | Power | The Power and LED Panel Wires must be Oriented Downward to Prevent Water Intrusion.
|
Earthing | Lighting Safety Precautions must be Taken and Power Wires must be Grounded.
| |
| Settings | Gently Modify the Bolt of Brightness, Sensor and Time | |
| Installation | Professional Electricians or Quality Technicians Should Install and Adjust.
| |
| Caution | Do not open the case and remove the power supply. |
| Part Number | Description | Standard Quantity |
| ENI-ISA010-040R | IR Strobe Illuminator with 40 Pieces High Power IR LED, 10° Beam Angle, 40m IR and IP66 Support | 1 |
